Box removal

Anyone have a how to or pictures or diagrams on the removal of the flareside box year 2000? Also the length of time it would take?


2000 F150 SUPERCAB FLARESIDE 4X4 5.4L
EDDIE BAUER EDTION EXPEDITION 4X4 5.4L
2003 FORD ESCAPE XLT 4X4
NEW! F-250 Super Duty 4x4 Xlt Sc
xllxll_VIPER_llxllx is offline
Sponsored Links
Advertisement

post #2 of 23 (permalink) Old 02-20-2010, 04:05 PM

LayinHp's Avatar

Join Date: Feb 2007
Location: Waterford
Posts: 3,019
box side or whole box off frame ?

should be just the 4 bolts (maybe 6) undo the fuel door setup at the rear unplug the tail light harness

and lift it off....



2007 F350 6.0L Ext cab short box 4x4
2000 F150 5.4L Reg cab short box 2wd
?? always looking for a new ford project !
LayinHp is offline
post #3 of 23 (permalink) Old 02-20-2010, 05:20 PM Thread Starter

xllxll_VIPER_llxllx's Avatar

Join Date: Dec 2009
Location: Guelph
Posts: 149
Send a message via MSN to xllxll_VIPER_llxllx
Quote:
Originally Posted by LayinHp View Post
box side or whole box off frame ?

should be just the 4 bolts (maybe 6) undo the fuel door setup at the rear unplug the tail light harness

and lift it off....
Thanks dude..... ya its the whole box... i really dont have to do this but i'm very picky about the care of my truck so i figured that when i repaint the truck this spring i might as well go all the way and remove the box and do the frame and all..... my floors and frame are mint even tho i plow with this truck... i want to keep it that way. Thanks for the info... i didnt think it would be more then 6 bolts on the 6.5 ft bed and since its the flareside and the majority of the box is fiberglass it would be to heavy


2000 F150 SUPERCAB FLARESIDE 4X4 5.4L
EDDIE BAUER EDTION EXPEDITION 4X4 5.4L
2003 FORD ESCAPE XLT 4X4
NEW! F-250 Super Duty 4x4 Xlt Sc
xllxll_VIPER_llxllx is offline

post #4 of 23 (permalink) Old 02-20-2010, 07:06 PM

SKRWZ's Avatar

Join Date: Nov 2007
Location: Burlington
Posts: 3,896
This is from the 1998 Ford service manual should be the same as your truck
---------------------------------------------------------------------

Pickup Bed

Removal
1. If equipped, roll up the tonneau cover.
2. Remove the fuel filler neck screws.
3. Disconnect the tail lamp harness electrical connector.
4. Disconnect the license plate lamps.
5. If equipped, unhook the trailer wiring harness electrical connector from the bumper.
6. Remove the fuel filler pipe to pickup bed clamp.
7. Disconnect the rear axle vent tube from the pickup bed.
8. CAUTION:
Use care not to scratch the pickup bed.

If equipped with a 1.98 m (6.5 ft) bed, remove the bolts.
9. CAUTION:
Use care not to scratch the pickup bed.

If equipped with a 2.43 m (8 ft) bed, remove the bolts.
10. CAUTION:
Use body decking protectors over the front corners of the pickup bed to prevent scratches.
CAUTION:
Lifting the pickup bed requires at least two people on each side.

Remove the pickup bed.







http://www.fordtough.ca/forums/signaturepics/sigpic435_3.gif
SKRWZ is offline
post #5 of 23 (permalink) Old 02-20-2010, 07:21 PM Thread Starter

xllxll_VIPER_llxllx's Avatar

Join Date: Dec 2009
Location: Guelph
Posts: 149
Send a message via MSN to xllxll_VIPER_llxllx
Thank you sir! I'm assuming its held on by 6 carriage bolts? Thanks for the pics!


2000 F150 SUPERCAB FLARESIDE 4X4 5.4L
EDDIE BAUER EDTION EXPEDITION 4X4 5.4L
2003 FORD ESCAPE XLT 4X4
NEW! F-250 Super Duty 4x4 Xlt Sc
xllxll_VIPER_llxllx is offline
post #6 of 23 (permalink) Old 02-20-2010, 07:37 PM

SKRWZ's Avatar

Join Date: Nov 2007
Location: Burlington
Posts: 3,896
The box bolts are a T 50 or T 55 Torx head soak them in oil daily for a week or two prior to removal this should help you get them out with out heat

http://www.fordtough.ca/forums/signaturepics/sigpic435_3.gif
SKRWZ is offline
post #7 of 23 (permalink) Old 02-20-2010, 07:48 PM Thread Starter

xllxll_VIPER_llxllx's Avatar

Join Date: Dec 2009
Location: Guelph
Posts: 149
Send a message via MSN to xllxll_VIPER_llxllx
Quote:
Originally Posted by SKRWZ View Post
The box bolts are a T 50 or T 55 Torx head soak them in oil daily for a week or two prior to removal this should help you get them out with out heat
Thanks very much for the info.... now i just have to wait for spring! What should they be torqued back to when reinstalling them? i also believe i'd use locktite to keep'em from coming loose.


2000 F150 SUPERCAB FLARESIDE 4X4 5.4L
EDDIE BAUER EDTION EXPEDITION 4X4 5.4L
2003 FORD ESCAPE XLT 4X4
NEW! F-250 Super Duty 4x4 Xlt Sc
xllxll_VIPER_llxllx is offline
post #8 of 23 (permalink) Old 02-20-2010, 08:03 PM

Northern Supercrew's Avatar

Join Date: Jan 2008
Location: watson lake, yukon
Posts: 4,280
Send a message via MSN to Northern Supercrew
I just went thru my 97-00 Chilton manual and i can't even find how to remove the box in there much less the torque specs. I would torque em till they break...then back off 1/2 turn

2013 f150 Ecobeast
3.55 E locker
FX4 Screw
SSI tuned!!!!!!!!!!!!!!!!!
Northern Supercrew is offline
post #9 of 23 (permalink) Old 02-20-2010, 08:09 PM Thread Starter

xllxll_VIPER_llxllx's Avatar

Join Date: Dec 2009
Location: Guelph
Posts: 149
Send a message via MSN to xllxll_VIPER_llxllx
Quote:
Originally Posted by Northern Supercrew View Post
I just went thru my 97-00 Chilton manual and i can't even find how to remove the box in there much less the torque specs. I would torque em till they break...then back off 1/2 turn
lol thanks for the advice


2000 F150 SUPERCAB FLARESIDE 4X4 5.4L
EDDIE BAUER EDTION EXPEDITION 4X4 5.4L
2003 FORD ESCAPE XLT 4X4
NEW! F-250 Super Duty 4x4 Xlt Sc
xllxll_VIPER_llxllx is offline
post #10 of 23 (permalink) Old 02-20-2010, 09:04 PM

SKRWZ's Avatar

Join Date: Nov 2007
Location: Burlington
Posts: 3,896
Quote:
Originally Posted by Northern Supercrew View Post
I just went thru my 97-00 Chilton manual and i can't even find how to remove the box in there much less the torque specs. I would torque em till they break...then back off 1/2 turn

I would say 45-55 FT Pounds should be enough

http://www.fordtough.ca/forums/signaturepics/sigpic435_3.gif
SKRWZ is offline
